Engine Engine Type: Single Cylinder, 4 stroke Displacement: 686 CC Refrigeration: Liquid Direction: Electrical (Intelligent EPS System) Start-up: Electric start Power (kw/rmp): 16.8Kw/7000 rpm Max torque (Nm/rpm): 25.5 N-m/5500 rmp Streaming: Automatic CVT with reverse gear
Homologation: T3b (2 places)
Power system: Electric injection
Chassis
Front suspension: High performance double A-arm – Oil pressurized
Shock absorbers: Hydraulic
Rims: Iron Hoop 10″
Front tire: GA 300 FO: 24×8-12″ | GA 300 PRO: 22×7-10″
Rear Suspension: Swing Arm
Brakes (Front and Rear): Hydraulic disc
Parking brake: Yes
Rear tire: GA 300 FO: 24×10-12″ | GA 300 PRO: 22×10-10″
Dimensions and Weight
Dimension (LxWxH mm): 1940x1095x1150mm
Wheelbase (mm): 1210mm
Seat height (mm): 878mm
Tank capacity: 14L
Net weight (kg): 245kg
Ground clearance (mm): 165mm
